Rigid vs Flexible Chimney Liner


When it comes to ensuring the safety and efficiency of your chimney, selecting the right type of liner is crucial. Chimney liners serve to protect your home from heat transfer and prevent the accumulation of hazardous gases. Among the options available, stainless steel liners stand out for their durability and effectiveness. However, within this category, you must choose between rigid and flexible liners. This article will delve into the differences between rigid and flexible chimney liners, helping you make an informed decision based on your specific needs.

Understanding Rigid Chimney Liners

Rigid chimney liners are made from solid, straight sections of stainless steel and are best suited for chimneys with a straight path without any offsets or significant bends.


Durability: Rigid liners are incredibly durable and resistant to corrosion and heat, making them ideal for wood-burning appliances.
Efficiency: They offer a smooth interior surface that improves airflow and draft, enhancing the efficiency of your heating appliance.
Longevity: With proper maintenance, rigid liners can last for decades, providing a long-term solution for your chimney.

Installation Challenges: Rigid liners can be difficult to install in chimneys with bends or offsets. The installation process may require more extensive modifications to the chimney structure.
Cost: Due to their durability and material quality, rigid liners can be more expensive upfront than their flexible counterparts.

Understanding Flexible Chimney Liners

Flexible chimney liners, on the other hand, are made from corrugated stainless steel that can bend and adjust to the contours of your chimney. This flexibility makes them suitable for chimneys with bends, offsets, or irregular shapes.


Versatility: Flexible liners can be maneuvered through complex chimney structures, making them ideal for retrofitting older chimneys that do not have a straight path.
Ease of Installation: The flexibility of these liners significantly simplifies the installation process, often resulting in lower labor costs.
Adaptability: They can accommodate the expansion and contraction caused by temperature changes, reducing the risk of damage over time.

Maintenance: The corrugated interior surface can accumulate creosote and soot more easily than the smooth surface of rigid liners, potentially requiring more frequent cleaning.
Durability: While still highly durable, flexible liners may not last as long as rigid liners in certain conditions, especially when used with high-temperature appliances like wood stoves.

Choosing Between Rigid and Flexible Liners

The choice between rigid and flexible chimney liners depends on several factors:

Chimney Structure: If your chimney is straight without any offsets, a rigid liner may be the best option. For chimneys with bends or irregular shapes, a flexible liner will be necessary.
Type of Appliance: Wood-burning appliances that produce high temperatures and corrosive by-products may benefit more from the durability of rigid liners. Flexible liners, however, can be a good choice for gas or oil appliances.
Installation Considerations: If ease of installation and lower initial costs are priorities, flexible liners offer advantages. For those focusing on long-term durability and performance, rigid liners may be preferable.


Both rigid and flexible chimney liners have their place in maintaining the safety and efficiency of your chimney system. Your specific situation—considering your chimney’s architecture, the type of fuel you use, and your budget—will determine the best option for you. Regardless of your choice, ensuring that your chimney liner is correctly installed and regularly maintained is key to protecting your home and ensuring the efficient operation of your heating appliance.

Why Choose Stainless Steel Chimney Liner

Chimney Liner Coils

Choosing the right material for your chimney liner is crucial for the safety, efficiency, and longevity of your chimney system. Among the various options available, stainless steel stands out as the premier choice for homeowners and professionals alike. This article explores the compelling reasons why a stainless steel chimney liner is often the best option for your home.

Durability and Longevity

One of the most significant advantages of stainless steel chimney liners is their exceptional durability. Stainless steel is highly resistant to corrosion and rust, which are common issues with other materials exposed to the harsh conditions inside a chimney. This resistance ensures that your stainless steel liner can withstand the acidic by-products of combustion, moisture, and extreme temperatures without deteriorating over time. As a result, stainless steel liners often come with longer warranties, some extending for the lifetime of the liner, providing peace of mind and reducing long-term costs.

Improved Safety

Safety is a paramount concern when it comes to chimney operation. Stainless steel chimney liners provide a secure conduit for harmful gases produced during combustion to exit your home. Their robust construction minimizes the risk of cracks and gaps that can occur in older clay tile liners, significantly reducing the likelihood of carbon monoxide leakage or chimney fires. By maintaining a consistent flue size and smooth surface, stainless steel liners also improve draft, further enhancing the safe operation of your fireplace or stove.


Stainless steel liners are suitable for all types of fuels, including wood, gas, oil, and coal. This versatility makes them an ideal choice for any heating appliance, whether you are installing a new system or upgrading an existing one. Additionally, stainless steel liners can be fitted into any chimney, regardless of its shape or size, thanks to flexible and rigid options. This adaptability ensures that homeowners can benefit from the advantages of a stainless steel liner, no matter their specific requirements.

Energy Efficiency

Installing a stainless steel chimney liner can enhance the energy efficiency of your heating system. The smooth interior surface of stainless steel improves airflow and reduces the buildup of creosote, ensuring that your fireplace or stove operates more efficiently. This can help in reducing fuel consumption and lowering heating costs. Furthermore, the tight seal formed by a properly installed stainless steel liner prevents heat loss, keeping your home warmer during the colder months.

Ease of Maintenance

The maintenance of a chimney liner is critical for its performance and safety. Stainless steel liners are easier to clean compared to other materials, as their smooth surface allows for the efficient removal of soot and creosote. This ease of maintenance not only simplifies the cleaning process but also contributes to the overall safety and efficiency of your chimney system.


Choosing a stainless steel chimney liner offers numerous benefits, including durability, safety, versatility, energy efficiency, and ease of maintenance. These advantages make stainless steel an ideal material for homeowners seeking to enhance the performance and safety of their chimney systems. With its long-term value and proven performance, a stainless steel chimney liner is an investment in the safety and comfort of your home.

Chimney Liner Depot offers the best price on Stainless Steel Chimney Liners because we own the factory that manufactures them, ensuring no middlemen inflate your costs.

The Essential Guide to Chimney Top Plates: Ensuring Safety and Efficiency


A well-functioning chimney is crucial for maintaining the safety and efficiency of any fireplace or wood-burning stove. Among the various components that make up a chimney system, the chimney top plate plays a significant role in protecting your home from external elements while allowing for proper ventilation. In this article, we will explore the importance of a chimney top plate, its functions, and why investing in a high-quality product is essential. If you’re looking to enhance your chimney’s performance, read on!

Understanding the Chimney Top Plate:

The chimney top plate, also known as a chimney cap or chimney crown, is a protective covering that sits at the topmost part of a chimney. It serves as a barrier against rain, snow, debris, and animals, preventing them from entering the chimney and causing potential damage. Furthermore, a well-designed chimney top plate also facilitates proper airflow, preventing downdrafts and ensuring efficient ventilation.

Functions and Benefits:

Weather Protection: The primary purpose of a chimney top plate is to shield your chimney from the elements. Rainwater and melting snow can cause significant damage to the interior of your chimney, leading to costly repair. By installing a top plate, you can prevent water entry, preserving the structural integrity of your chimney and avoiding potential leaks.

Debris and Animal Prevention: Leaves, twigs, and other debris can find their way into an unprotected chimney, creating blockages and reducing airflow. Additionally, birds, squirrels, and other small animals may attempt to build nests in chimneys, posing a fire hazard. A chimney top plate acts as a barrier, preventing debris and animals from entering your chimney, ensuring a clear and safe passage for smoke and gases.

Increased Ventilation Efficiency: Proper ventilation is crucial for maintaining optimal performance and preventing harmful gases, such as carbon monoxide, from accumulating in your home. A well-designed chimney top plate helps create a balanced airflow, reducing the likelihood of downdrafts and improving overall ventilation efficiency.

Invest in Quality:

When it comes to chimney top plates, investing in a high-quality product is of utmost importance. Opting for a durable and well-constructed chimney top plate ensures long-lasting protection for your chimney and reduces the need for frequent replacements or repair.

At Chimney Liner Depot, we take pride in manufacturing top-quality chimney top plates that guarantee superior performance and longevity. As the owners of the factory where our products are made, we have full control over the manufacturing process, ensuring strict quality control measures are followed. By choosing our chimney top plates, you can trust that you are investing in a product that will enhance the safety and efficiency of your chimney for years to come.

A chimney top plate is an essential component of any chimney system, providing protection against the elements, preventing debris and animals from entering, and improving ventilation efficiency. To ensure maximum safety and longevity for your chimney, it is crucial to invest in a high-quality chimney top plate. At Chimney Liner Depot, we offer top-of-the-line chimney top plates, manufactured with the utmost care and quality control. Purchase our chimney top plates today, and rest assured that your chimney will receive the protection it deserves. Quality guaranteed, as we proudly own the factory where our products are made.

Checkout our complete list of Top Plate products.

If you need assistance with the installation of your chimney top plate, don’t hesitate to contact Spring Hill Chimney, your trusted experts in chimney services

Chimney Repair – NEPA, Scranton, Moscow, Gouldsboro, Dupont, Wilkes Barre


If your chimney needs to be cleaned and you live in Scranton, Pennsylvania, you can rely on Spring Hill Chimney Service. They’re a full-service chimney company that can handle projects of all sizes. They’re proud of their work and they’ll always make sure you’re happy with the service you receive.

At their company, they specialize in installing stainless steel chimney liners. What makes them unique is that they have their own factory where they make all the stainless steel chimney liners and components they install. If you want to see for yourself how their chimney liners are the best quality and value, just ask to see some samples.

They install high-quality stainless steel chimney liners.

If you need to get your chimney fixed in Olyphant, PA, Spring Hill Chimney Service is the best company to call! They’ll make sure your chimney is repaired quickly and efficiently.

They can make anything you want out of metal!


Chimney Repairs of all kinds
Stainless Steel Chimney Relining
Chimney Cleaning
Chimney Inspections
Fireplace or Chimney Troubleshooting
Chimney Waterproofing
Chimney Caps
Custom Stainless Chase Top Installation
New Chimneys Built / Chimney Installation
Firebox Rebuilds
Smoke Chamber Repair
Chimney Removal

Project Gallery:

Now is a fine time to reline your chimney


Many people think that when the cold weather hits that they should probably wait until next year to tackle the chimney relining project they have been planning. The truth is it’s easier to do any outside project when the weather is nice. However, now is a great time to purchase a stainless steel chimney liner. We are running specials every day that can save you a decent amount of greenbacks. Give us a call today at 1-866-941-5112 for help with your chimney relining project. Click here to answer a few questions online about your chimney relining project and we will recommend a product that best suites your needs.

Professional Grade Class A Chimney Pipe


class-a-groupAt Chimney Liner Depot we not only carry top of the line stainless steel chimney liners, but we also carry an industry leading Class A chimney system brand. We are proud to offer Metal Fab’s TempGuard Class A chimney products. This double wall insulated chimney system is manufactured right here in the U.S.A. It’s nice to know that the chimney product you are installing in your home is manufactured right here at home.

Installing a Class A chimney system is definitely a project a competent DIYer can handle. If you are familiar with building techniques and know your way around your home, you can feel confident installing a chimney system. We can help you select the proper components. Give us a call today for assistance with your Class A Chimney project, 1-866-941-5112.



Sometimes installing a Stainless Steel Chimney liner for your fireplace insert can be difficult.  Sometimes the flue outlet is too far forward and you cannot directly connect the chimney liner to the stove.  You may feel like it is impossible to do, but there is an adapter that can make your life easier.  Check out these 2 adapters that could be a life saver.

The first one is a boot adapter, it gives you and angled positive connection when the liner is coming down at and angle and doesn’t make a flush fit into the stove.

The second is a offset box adapter when you cannot pull the liner far enough forward to insert into the stove.  Knowing that these products exists could save your day.

insert boot2014-05-12 14.05.08




Have you tried our Live Chat???

Categories: Tags:

Do you have questions and need help sometimes while you are browsing our site?  Do you not feel like picking up the phone and talking to someone and asking for help?  Remember there are no dumb questions.  Ask for help before you buy the wrong item.

Click the live chat button, we almost always have live Tech help online waiting for you.  If they are away from the computer, leave us a message and we will get back to you asap.  Always ask before purchasing.

lLive Chat Help

Facebook Deals


Don’t forget to check us out on Facebook. We have secret sales only listed on Facebook.


Our Flexible Chimney Liners


Chimney Liner Our Flex King Liner is best for gas or oil.

The Flex King Pro has a smooth inner wall making it a great liner for wood or coal.  It increases draft and reduces creosote buildup with the use of wood burning appliances.  The Flex King Pro can used for all fuels.  It is a great option to use with gas and oil appliances because it can handle 25% more BTU’s than the standard Flex King Liner.

The Flex King HD is best to use if you have a wood stove or furnace that you plan on burning all winter.  If you rely on the wood stove to heat your home, this is the liner you need!  It is the strongest, most durable flexible liner we make.  As you can see it is also smooth reducing creosote build up.

All of our Chimney Liners are UL listed to UL1777.

7″ Flex Liner Elbow Sale!!!!


We have a surplus of 7″ flex liner elbows, both 45 degree and 90 degree elbows.  Call now and ask for a 25% discount on these elbows.  All other elbows are normal price.flex elbow

Don’t forget to check us out on Facebook for special offers also.  www.Facebook.com

Skip the Middle Man


Why would you go to a car dealership to buy a car if you could go right to the factory and get the same car at a huge discount?

That is the question we ask ourselves all the time. Why would anyone not buy a chimney liner from us?? We are the manufacturer, we make all our stainless steel products, never purchased overseas and resold to you. Skip the middle man and save big time.

Buy from us and SAVE!!!

#1 in Customer Service!!!


“I recently purchased a liner system for my chimney from y’all. I wanted to take the time and say THANK YOU! for the excellent service, fast delivery, and for Henry’s extreme patience and help with all my incessant questions. I have recommended your company to quite a few of my associates and I’m sure they will be happy too!”

Regards, Jeff

We love hearing from our Customers!!


Please tell us about your great experience with Chimney Liner Depot on our Facebook page.  You will also receive special promotions and coupon codes only advertised on Facebook.

Here is our latest customer feedback:

“Last Thursday, 9/12/13, I ordered a chimney liner kit from you. I ordered a 6’X20′ Flex King liner kit with cap, tee, liner and top plate. On Friday 9/13 I received a tracking email and by the time I got home from work it was there!

I recently hurt my shoulder in an accident and am one arm down. I enlisted the help of my father to do the install. After getting the parts laid out and prepping the work area, my dad and my disabled self had the whole liner installed and ready to go within 2 hours!

I really appreciate your professional service and complete kits. I researched these liners for 2 years before I made this purchase and just wanted to say thanks and you are appreciated.”

-Mike Snow

Special offers on Facebook!!


Do you want special offers and the latest news on our product line?  Like us on Facebook and you will be notified of promotions only advertised via Facebook.

Chimney liners are not cheap.  We all want to save some money.  We can help you with purchasing the highest quality chimney liner at the best price.  We are the manufacture of all our stainless steel chimney liners and components.  You can save even more by following us on Facebook.


Chimney Repair Season is Here


Even though it is summer time, the chimney season is right around the corner. Now is the time to get good deals on flexible chimney liners and other chimney repair products. Chimney Liner Depot offers high quality american made chimney relining products. We are experts at what we do, so give us a call and let us help you with your chimney relining project.

Click here for the best pricing on quality chimney liners.

Follow us on Facebook for Chimney Liner Sales

Categories: Tags:

Do you want chimney liner sales that are not available to everyone?  Would you like free upgrades?  Do you want a chance to win a FREE cleaning kit?  Follow us on Facebook, we will almost always have a sale or an offer of some type only advertised on our Facebook page, Click Here.

Right now we have special chimney liner sales on….well you will have to go check us out.  It is the best sale on internet right now for a stainless steel chimney liner.  Let us know what you would like to have on sale.  Show us pics of your installs.  Show us before and after pics.  Ask for tech help.  Or just tell us how you are doing.  We love hearing from our customers, this way we can know where we can improve and where we are exceeding.

Visit Chimney Liner Depot now on Facebook to check out the latest chimney liner sales.

special offer chimney liner, chimney liner sale

Chimney Liner Depot End of Year Sale


Chimney Liner Depot is running a huge sale to reduce inventory before the end of the year. 20% off all flexible liner kits. Now is the time to get the bests prices anywhere on a high quality chimney liner. Don’t wait because the sale is over once our inventory is reduced. Liners are going fast, so give us a call today.

Black Friday Chimney Liner Deals


Make sure to check out Chimney Liner Depot on Black Friday. We are going to have a great sale. Now is the time to buy a chimney liner. Don’t wait any longer. Before you know it the snow will be here. The weather is perfect for installing a chimney liner. Our stainless steel chimney liners are the best in the industry. Our chimney liners are made from the best materials and made right here in the United States.

What is a chimney liner?


A chimney liner is design to be installed in an existing chimney. Prefab chimneys and masonry chimneys are existing chimneys that can have chimney liner installed in them. A chimney liner is not to be confused with an actual chimney. Masonry chimneys usually have clay flue tiles. These flue tiles can break down over time. Different factors can contribute to this break down. A rigid or flexible stainless steel chimney liner is designed to be inserted in the chimney replacing the function of the clay flue liner.

It’s fall, it’s time to look at your chimney


Every year during the fall season there is a sudden increase in chimney liner sales. Most people start thinking about chimneys during the fall months. It certainly is the season to inspect your chimney and if needed, install a chimney liner. There are two types of stainless steel chimney liners that can be installed. A rigid chimney liner is by the best stainless steel chimney liner that you can install in your chimney. For more information about stainless steel rigid chimney liners click here. Rigid chimney liners are good in situations where the masonry chimney does not have any bends in it. If the masonry chimney does have bends then a flexible stainless steel chimney liner is the next best option. Click here for more information about flexible stainless steel chimney liners.

Why Insulate your chimney liner


Here is a link that talks about chimney liner insulation. Why it is important to insulate your chimney liner. Is insulating a chimney required to maintain a UL Listing?

Class A Stainless Steel Chimney System


Check out this great information on a class a chimney system.

Chimney Chase Cover


What is a chase cover? A chase cover is a metal covering of a chimney chase. The chimney chase can be made of wood which would house a Class A Chimney system or it can be considered a masonry structure. Most masonry chimneys are protected on top by a masonry crown. This deflects water and protects the actual brick or block of the chimney.

Stainless steel chimney chase covers are a good way to protect a wood chase. A lot of chimney chases were built over the years with a galvanized or painted steel chase cover on top for protection. Over time these chase covers started to rust out. The best way to solve this problem or eliminate it on new construction is to install a stainless steel chimney chase cover.

Chimney Liner Depot has an in-house chase cover department that can custom manufacture any chimney chase cover that you may need. We can make them out of a variety of materials, but the most cost efficient and long lasting solution is a stainless steel chimney chase cover.

Give us a call today at 1-866-286-1062 to order your chimney chase cover. It’s is a simple process. We will ask you for a few dimensions and get to work on your custom chimney chase cover. Shipping is fast, and the warranty is forever. Your chase cover is guaranteed never to rust.

Click here for a quick price quote on your custom chimney chase cover.

Flexible Chimney Flue Pipe can Bring New Life to Your Chimney


The chimney liner is the ultimate solution to the problems that plague most chimneys. Modern stainless steel provides air tight and water tight barrier that seals in gases and creosote. Underwriters Laboratory declared that flex systems excel standards for chimney safety and can even withstand a chimney fire and still maintain structural integrity.

This system is to be installed in all new or existing masonry chimneys that are used for the natural draft venting of gas, liquid, and solid fuel fired residential type appliances and masonry fireplaces. While extreme care has been taken to make the system as safe as possible, proper installation, operation and maintenance should be followed.

316TI Stainless Steel is the Best Stainless Steel for Chimney Liners
316TI is a stainless steel alloy with a small amount of titanium added. It’s make-up allows it to resist acids and the stresses of hot and cold cycles. It can be used with solid fuels (wood, coal and pellet), gas and oil. It can withstand temperatures up to 2100 degrees.

If your masonry chimney is suffering from problems due to a newer appliance, the solution is to install a stainless steel chimney liner.

    *Note: If you have a terra cotta clay chimney
    flue lining, be sure to measure the true length and width of the
    inside of your chimney flue space.

    *If there is a terra cotta clay flue liner, does it protrude out of
    the top of the chimney at least 2 inches? If there are at least 2
    inches and the terra cotta clay is in good condition, you will use
    our stainless steel, terra cotta top plate that has a 1 1⁄2inch edge
    that goes all the way around (like a shoebox lid).

    *If your terra cotta clay flue is in bad shape at the top, you may
    need to just take a hammer and tap all around that terra cotta,
    taking it away to make the surface flat at the top of your chimney.
    In that case, you will simply use the flat top plate that comes with
    our liner kit.

    *Note: If you have a terra cotta clay chimney
    flue lining, be sure to measure the true length and width of the
    inside of your chimney flue space.

    *If it is on the back of the stove, is it parallel with the back of the stove or is it at an angle, like 45 degrees?

    *If it is at an angle you will use an insert stove adaptor (an insert liner kit) rather than a two-part tee with cleanout cap.

    Usually pellet stoves have an exhaust hole id of 3 inches. However, if you are going up more than 15 feet to the top of your chimney you need to use a pipe and/or flex liner that is 4 inches diameter.

    If you are only venting a hot water heater then the exhaust hole diameter is probably 3 inch diameter. If it is 3 inch diameter and you are going up more than 15 feet to the top of your chimney, you must use a 4 inch diameter flexible liner or ridged pipe for proper draft. We also suggest to go ahead and use a 4 inch diameter flexible liner or ridged pipe even if the total length is 15 feet or less.

    Not the depth or any other dimension inside your fireplace.

    Most gas log fireplaces require an 8 inch liner kit or rigid kit. But do not assume that is the case for the gas log fireplace kit you are installing. Obey the requirements for that specific unit that are in your installation/instruction manual.
